25Gbps 850nm PIN-TIA TO-CAN Series
Features：
● Data rates up to 25 Gbps.
● 850nm multimode.
● Single +3.3V Power Supply.
● -40℃ to 85℃ Operation.
● Received signal strength indicator(RSSI).
Applications：
●High speed Data Communication.
Specifications：
Absolute Maximum Ratings:
|
Parameter
|
Symbol
|
Min.
|
Max.
|
Unit
|
|
Optical Input Power
|
Pin
|
|
5
|
dBm
|
|
Operating Temperature
|
Top
|
-40
|
+85
|
℃
|
|
Storage Temperature
|
Tstg
|
-40
|
+85
|
℃
|
|
Lead Solder Temperature
|
|
|
260
|
℃
|
|
Lead Solder Time
|
—
|
—
|
10
|
s
|
Characteristics：（Ta=25℃ unless otherwise noted）
|
Parameter
|
Symbol
|
Test Conditions
|
Min.
|
Typ.
|
Max.
|
Unit
|
|
Supply Voltage
|
Vcc
|
|
2.97
|
3.3
|
3.63
|
V
|
|
Supply Current
|
Icc
|
Vcc=3.3V
|
—
|
26
|
33
|
mA
|
|
Wavelength Range
|
λ
|
Vcc=3.3V
|
820
|
850
|
860
|
nm
|
|
RSSI Dark Current
|
Id
|
Vcc=3.3V
|
|
|
100
|
nA
|
|
Bandwidth
|
BW
|
-3dB
|
--
|
21
|
—
|
GHz
|
|
Overload
|
OL
|
Vcc=3.3V
|
-3
|
—
|
—
|
dBm
|
|
Sensitivity
|
Sen
|
25.78Gbps,PRBS31
850nm,ER=4dB,
BER= 10E- 12
|
—
|
—
|
-9
|
dBm
|
